A-B SK-20P-S5N07 Pulse Transformer Board for Industrial Automation, 230VAC
The A-B SK-20P-S5N07 Pulse Transformer Board is designed for high-performance applications requiring precise signal isolation and conversion. It is ideal for industrial automation systems, communication devices, and control panels where reliable pulse transmission is critical.
Voltage Rating:230VAC
Frequency Range:50/60Hz
Isolation Voltage:2500VAC
Operating Temperature:-40°C to +85°C
Dimensions:95mm x 45mm x 30mm
Weight:150g
Input Impedance:10kΩ
Output Impedance:10kΩ
Coupling Capacitor:100nF
Pulse Width:500ns
Insulation Material:Polyester Film
Connector Type:Phoenix Contact
This pulse transformer board is engineered to withstand harsh industrial environments, making it ideal for use in power supply units, inverters, and other critical control system components.
The SK-20P-S5N07 is built with high-quality materials ensuring longevity and reliability under varying conditions.
Installation is straightforward, with clear labeling on the board facilitating easy connection to control circuits.
Designed for optimal performance, this pulse transformer board supports efficient signal transmission, contributing to the overall reliability of industrial automation systems.
Backed by Rockwell Automation’s renowned customer support and warranty services, the SK-20P-S5N07 ensures peace of mind for users seeking dependable solutions.
