Allen Bradley 1746-NIO4V/A SLC500 High Resolution Analog Combination Module

Allen Bradley 1746-NIO4V/A SLC500 High Resolution Analog Combination Module

    The Allen-Bradley 1746-NIO4V/A is a high-resolution analog combination module designed for industrial automation systems. It offers precise input and output capabilities, making it ideal for various applications such as process control, manufacturing, and data acquisition.

Manufacturer:Allen Bradley

Model Number:1746-NIO4V/A

Module Type:SLC500

Number of Channels:2 Input, 2 Output

Input Range:-20 to 20 mA

Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (Max)

Common Mode Voltage Range:-20 to 20 V

Output Range:-10 to 10 V – 1 LSB

Full Scale Output:10 VDC

Overvoltage Protection:7.5 VAC RMS

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 55 mA

    The Allen-Bradley 1746-NIO4V is a top-tier analog combination module designed for industrial control systems. Its high-resolution capabilities allow for precise data acquisition and control, making it ideal for a variety of industrial automation applications. With two input and two output channels, this module offers flexibility in connecting various sensors and actuators. The robust design ensures reliable performance even in harsh industrial environments. The module features overvoltage protection to safeguard against electrical spikes and surges, ensuring long-term reliability. Installation is straightforward, allowing quick setup and integration into existing systems. The 1746-NIO4V is an essential component for any industrial control system requiring accurate and dependable analog signal handling.
