B&R 3EX3506 Bus Control Module, I/O Module for Industrial Automation

B&R 3EX3506 Bus Control Module, I/O Module for Industrial Automation

    The B&R 3EX3506 Bus Control Module is designed to enhance automation systems in industrial environments. It supports high-speed data transfer and robust connectivity, making it ideal for applications requiring precise control and monitoring.

Module Type:Bus Control Module

Model:3EX3506

Manufacturer:B&R

Data Rate:Up to 100 Mbps

Communication Protocol:EtherCAT

Number of Channels:8

Power Supply:24 VDC

Operating Temperature Range:-25°C to +60°C

Storage Temperature Range:-40°C to +85°C

Dimensions (HxWxD):60 x 125 x 100 mm

Weight:Approx. 0.4 kg

Certifications:CE, UL, ATEX

    The B&R Bus Control Module 3EX3506 stands out for its advanced design and high reliability.

     With support for PROFINET and Ethernet/IP protocols, it ensures seamless integration with modern industrial systems.

     Its wide operating temperature range (-25°C to +60°C) and humidity resistance (up to 95% RH) make it suitable for harsh industrial environments.

     Featuring up to 8 channels with 14-bit resolution and a sampling rate of up to 100 kHz per channel, this module provides accurate and timely data acquisition.

     It supports both voltage (0-10 V) and current (0-20 mA) analog input types, making it highly versatile for various applications.
