GE 269PLUS-DO-100P-120 Motor Management Relay for Industrial Control Systems
The GE 269PLUS-DO-100P-120 is a high-performance motor management relay designed for comprehensive control and protection of industrial motors. It supports statistical record-keeping and seamless integration with programmable controllers and computers, making it ideal for modern industrial automation systems.
Brand:GE
Model:269PLUS-DO-100P-120
Resistance:100 Ohm
RTD Type:Platinum
Shipping Dimensions (W x H x D):11.40 x 7.50 x 16.00 inches
Shipping Weight:7.75 lbs
Ambient Temperature Range:-25°C to 60°C
Communication Interface:RS485 Modbus RTU
Relay Outputs:4 Output Relays
Analog Outputs:1 Programmable Analog Output
Digital Inputs:5 Factory-Programmed Digital Inputs
RTD Inputs:8 Programmable RTDs
Overload Curves:8 Standard Overload Curves
The GE 269PLUS-DO-100P-120 stands out as a premier choice for industrial applications where precise motor management is critical. With its built-in 100 Ohm platinum RTD for temperature monitoring, this relay ensures reliable performance under varying conditions. Designed with advanced microcomputer control, it provides comprehensive protection and control capabilities for medium-sized AC motors. The relay is equipped with 5 factory-programmed digital inputs and 8 programmable RTDs, making it highly versatile for different applications.
The compact and robust design of the 269PLUS-DO-100P-120 makes it ideal for integration into existing systems. Its ability to communicate via Modbus RTU over RS485 enables seamless integration with programmable controllers and computers for integrated plant control. The relay supports 1 programmable analog output and 4 output relays, further enhancing its flexibility and adaptability.
Key Features:
– Microcomputer-controlled for precise and reliable operation
– Keypad accessible for easy programming and monitoring
– Self-test alarm indicators for quick fault detection
– High durability and long-lasting performance
– Supports multiple overload curves for flexible application
– Designed for use in challenging industrial environments
Installation and setup of the GE 269PLUS-DO-100P-120 is straightforward, thanks to its intuitive design and detailed documentation. Regular maintenance is minimal, reducing downtime and associated costs. Upgradeable in the field, this relay ensures longevity and adaptability to changing industrial needs.
