GE 369-HI-0-M-0-0-0 Motor Management Relay: Optimizing Motor Protection & Control
The GE Multilin 369-HI-0-M-0-0-0 is a motor management relay designed for efficient motor protection and control. It features an optional metering package and waveform capture capabilities to reduce maintenance costs and minimize downtime.
Control Power nominal:20 VA
Control Power maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:Approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:Approx. 4.5 kg
Communications:Non-isolated RS232 port, RS485 port
Differential Switch Time Delay:<200 ms
Event Record Triggers:Power fail, alarms, self test, inhibit, trip, waveform capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0-0 Motor Management Relay is meticulously engineered for medium to large motors, offering unparalleled protection against a wide range of issues such as undervoltage, reverse power, and mechanical jams.
Its design allows users to fine-tune parameters like motor inrush current and cooling rates for optimal performance.
With built-in metering capabilities and data logging, it provides real-time insights into motor health, helping to prevent unexpected failures and maintain system reliability.
