GE 369-HI-R-M-0-D-0-E: Advanced Motor Management Relay for Industrial Control Systems
The GE 369-HI-R-M-0-D-0-E Motor Management Relay is designed to optimize industrial motor performance through precise monitoring and control. With built-in metering capabilities, waveform capture, and event reporting, this relay minimizes downtime and maximizes operational efficiency.
Number of Digital/Switch Inputs:6 optically isolated
Ambient Humidity:Maximum up to 95% non-condensing
Control Power Nominal:20 VA
Control Power Maximum:65 VA
Dimensions:Approximately 11.5 in H x 5.5 in W x 8.5 in L
Fuse:3.15 A H 250 V
Maximum Altitude:2000 m (max)
Phase Current Inputs:1 A and 5 A secondary
Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels
Ground Current Input Frequency:20 to 100 Hz
Weight:Approximately 10 lbs
The GE 369-HI-R-M-0-D-0-E is designed for efficient motor management in industrial settings. It leverages advanced technology to provide critical insights into system performance through waveform capture, event reporting, and data logging. These features enable users to identify potential issues early and maintain optimal motor operation.
This relay supports up to 6 optically isolated digital and switch inputs, ensuring reliable signal transmission. It operates under a wide range of ambient humidity conditions, making it suitable for various environments. The control power specifications are optimized for energy efficiency and robust performance.
With dimensions of approximately 11.5 inches in height, 5.5 inches in width, and 8.5 inches in length, the 369-HI-R-M-0-D-0-E is compact yet robust, fitting well within most industrial enclosures. It includes a 3.15 A H 250 V fuse for added safety and protection.
The device is capable of handling phase currents up to 1 A and 5 A secondary, making it versatile for different motor types and applications. It supports recording up to the last 512 events, providing comprehensive historical data for analysis and troubleshooting.
Equipped with RS232 and RS485 communication ports, the 369-HI-R-M-0-D-0-E facilitates seamless integration with other systems and devices. The waveform capture feature captures 3 buffers containing 16 cycles of all current and voltage channels, offering detailed diagnostic data.
