GE DS3800HLEA1B1B Logic Element Board – Industrial Control Systems Component
The GE DS3800HLEA1B1B Logic Element Board is designed for turbine control systems within the Mark IV series. It serves as a crucial component in advanced industrial control applications, providing robust performance and reliability.
Brand:General Electric
Model:DS3800HLEA1B1B
Module Type:Logic Element Board
Connector Type:Modular Connector
Indicator LEDs:10
Jumpers:3
Components:Resistors, Capacitors, TTL Interface Device
Air Dividers:Yes
Compatibility:Compatible with GE Drives and Turbine Controls
Certification:CE, RoHS Compliant
The GE DS3800HLEA1B1B Logic Element Board is a critical component designed for high-performance industrial control systems.
With its modular connector, this board can be easily attached to a drive and held securely by retention levers, ensuring stable operation under demanding conditions.
It features 10 indicator LEDs for easy status monitoring and 3 jumpers for custom configuration.
Built with robust components including resistors, capacitors, and a transistor to transistor logic (TTL) device, it offers reliable interface logic between integrated circuits.
Air dividers are strategically placed to optimize airflow over the components, enhancing thermal management and prolonging the board’s lifespan.
The board is meticulously crafted for durability and performance, making it an indispensable part of any industrial control setup.
