GE DS3800HPCA1F1E Digital Pulse Circuit Board, Suitable for Turbine Control Systems
The DS3800HPCA1F1E is a high-quality digital pulse circuit board designed by General Electric (GE), which forms a vital part of the Speedtronic Mark IV Line. It is primarily utilized in industrial control systems for precise regulation and management of turbine operations.
Brand:General Electric
Model:DS3800HPCA1F1E
Category:Digital Pulse Circuit Board
Dimensions:Varies per application
Weight:Varies per application
Power Requirement:Compatible with standard GE specifications
Operating Temperature Range:-40°C to +85°C
Humidity Range:0% to 95%, non-condensing
Compatibility:Fully compatible with GE turbine control systems
The DS3800HPCA1F1E is a robust and reliable component that enhances the efficiency of your industrial control system. This digital pulse circuit board features a compact design that allows for easy installation, requiring just two small screws and a pair of clips. Each letter from A through H and the letter J on the edge of the board indicates specific contact points, with small inverted triangles separating them. The board also includes five small LEDs for status indication, four of which are red and clustered together, while the fifth is yellow and stands alone. Adjacent to the yellow LED is a small red square, providing clear visual feedback during operation.
This board is meticulously crafted with precision engineering, ensuring seamless integration into existing turbine control setups. Its compatibility with standard GE specifications guarantees smooth operation without the need for additional modifications. With its advanced digital pulse technology, the DS3800HPCA1F1E contributes significantly to optimizing the performance of your industrial control systems, thereby enhancing overall productivity and reliability.
Whether you’re looking to upgrade your current system or implementing a new setup, the DS3800HPCA1F1E is a critical addition that can streamline processes and improve accuracy. Trust in the quality and expertise of General Electric to deliver exceptional results in your industrial applications.
