GE SR469-P1-HI-A20-E Motor Management Relay, Ideal for Industrial Control Systems
The GE SR469-P1-HI-A20-E is a robust motor management relay designed for industrial automation control systems. It monitors, controls, and protects medium to large-sized motors, ensuring reliable operation and minimizing downtime.
Manufacturer:General Electric
Model:SR469-P1-HI-A20-E
Protection Type:Overload, Short Circuit, Ground Fault
Operating Voltage:90-300VDC, 70-265VAC
Frequency Range:48-62Hz
Phase Current:5A
Analog Outputs:4
Current Rating:390/500 mA (MAX)
Enclosure Rating:20-X
Overvoltage Category:II
Insulation Voltage:300 V
Pollution Degree:2
RTD Inputs:Multiple RTD inputs for temperature and hotspot detection
RS-232 Interface:Programmable up to 19,200 baud
Installation Method:Draw-out unit with dust-deterring door
The GE SR469-P1-HI-A20-E Motor Management Relay is built for reliability and efficiency in industrial environments.
Featuring multiple RTD inputs, it can determine the actual temperature and hottest point of the motor system, using RTDs of 100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, and 100 ohm Platinum.
Designed with a robust drawout unit and dust-deterring door, this relay is easy to install following the instructions provided in the 1601-0122-AG manual.
Its front panel is user-friendly, equipped with an RS-232 interface for easy programming and control, with baud rates up to 19,200 for enhanced functionality.
The front panel also includes a secure draw-out handle that can be sealed against unauthorized access.
Ideal for safeguarding and enhancing the performance of medium to large motors, this relay ensures long-term operational excellence.
