GE SR489-P5-HI-A20-E – Motor Management Relay for Industrial Control Applications
The GE SR489-P5-HI-A20-E is a high-performance generator management relay designed for advanced protection and control applications in industrial environments. It offers comprehensive monitoring and protection capabilities, including trip and alarm functions, breaker failure detection, and digital input/output interfaces.
Manufacturer:General Electric Multilin
Model:SR489-P5-HI-A20-E
Series:489 Motor Management Relay
Current Inputs Accuracy:±5% of full scale
RTD Inputs Isolation:36 Vpk (isolated with analog inputs and outputs)
Phase Rotation:About the 489-P5-HI-A20
Digital Inputs:Configurable Assignable Digital Inputs 1 to 7
Humidity Operating Range:Up to 95% (Non-Condensing)
Shipping Weight:7.7 kg or 17 lbs.
The GE SR489-P5-HI-A20-E is a high-performance motor management relay designed for industrial applications requiring robust and reliable motor protection. With its advanced features and accurate monitoring capabilities, this relay ensures optimal performance and safety in demanding environments.
Key design highlights include fully drawout construction for automatic CT shorts, which enhances safety and reliability during maintenance operations. The relay supports multiple curve shapes and customizable settings, making it versatile for different applications. The integrated digital inputs and analog current outputs provide seamless integration with other control systems.
This relay is equipped with trip and alarm protection mechanisms, breaker failure detection, and VT fuse failure simulation, ensuring comprehensive protection against a wide range of faults. The included flash memory allows for easy configuration and data logging, simplifying maintenance and troubleshooting processes.
Furthermore, the 489 Enervista 489PC software facilitates interaction and programming of the relay directly from a PC, enhancing operational flexibility and efficiency. The SR489-CASE draw-out case is provided with new factory package versions, offering additional convenience and protection.
The SR489-P5-HI-A20-E is ideal for industries such as manufacturing, power generation, and automation, where precise control and reliable protection are paramount.
