General Electric 469-P1-HI-A20-E-H Motor Protection Relay

General Electric 469-P1-HI-A20-E-H Motor Protection Relay

    The GE Multilin 469-P1-HI-A20-E is an advanced motor protection relay designed to monitor, control, and safeguard medium to large motors. It provides comprehensive protection against overloads, short circuits, and other faults, ensuring the longevity and efficiency of your motor systems.

Brand:General Electric

Model:469-P1-HI-A20-E-H

Power Supply Range:90 – 300 Volt DC, 70 – 265 Volt AC, 48-62 Hz

Analog Outputs:Four (4) 0 to 1 mA analog outputs

Digital Inputs:Nine (9) opto-isolated inputs

Display:Enhanced display with larger LCD

Operating Temperature:-40°C to +60°C

Storage Temperature:-40°C to +80°C

Phase Current Inputs:1 A phase CT secondaries

Software:EnerVista 469 Setup

Enclosure Rating:20-X

Overvoltage Category:II

Insulation Voltage:300 V

Pollution Degree:2

    The GE Multilin 469-P1-HI-A20-E-H is a high-performance motor management relay engineered for demanding industrial applications. It boasts an enhanced front panel design, offering superior visibility and ease of use through its larger LCD display. The unit is equipped with nine opto-isolated digital inputs, providing reliable data transmission and fault detection. Four analog outputs allow for precise control over motor operations, ensuring efficient performance under varying conditions. Designed for harsh environments, it features conformal coating that protects against chemical damage. The relay supports a wide range of operating voltages and temperatures, making it ideal for diverse industrial settings. With its advanced software suite, the EnerVista 469 Setup, users can easily configure and monitor the relay’s performance, enhancing overall operational efficiency.
