National Instruments NI-9157 Real-Time Computing Module for CompactDAQ Systems
The National Instruments NI-9157 is an advanced FPGA module designed for high-speed data acquisition and processing. It offers real-time control and deterministic performance, making it ideal for industrial automation systems and test applications.
Module Type:CompactDAQ System Expansion Module
FPGA Technology:Xilinx Spartan-6
Sample Rate:Up to 1 MS/s per channel
Analog Input Channels:8 single-ended or 4 differential
Digital I/O:8 channels
Power Supply Requirements:9 VDC to 30 VDC
Connector Type:RJ45
Operating Temperature Range:-40°C to 85°C
Dimensions:3.81 cm x 9.4 cm
The National Instruments NI-9157 Real-Time Expansion Chassis is designed for applications requiring precise, reliable data acquisition. Its robust design and compatibility with CompactDAQ systems make it an ideal choice for industrial automation projects.
This expansion chassis supports up to eight module slots, allowing users to expand their data acquisition capabilities as needed. It is equipped with an integrated power supply, ensuring consistent performance in various environments.
The NI-9157 offers sub-microsecond synchronization accuracy, making it perfect for real-time applications. It is capable of operating in extreme temperatures ranging from -40°C to +85°C, ensuring durability and reliability in harsh conditions.
With its compact size and lightweight design, the NI-9157 can easily be integrated into existing systems without significant modifications. It’s an excellent solution for test & measurement setups, embedded systems, and any project demanding high precision and real-time performance.
Installation is straightforward, thanks to its intuitive design and clear documentation. This expansion chassis is not just a piece of hardware; it’s a cornerstone of your next big project.
