National Instruments PCI-5105 High-Speed Data Acquisition Module
The National Instruments PCI-5105 is a high-performance data acquisition module designed for industrial control systems. With 18 channels of analog input, it provides high-speed data acquisition capabilities ideal for real-time monitoring and control applications in manufacturing, energy, and process industries.
Brand:National Instruments
Model:PCI-5105
Interface:PCI
Analog Input Channels:16 Single-Ended or 8 Differential
Sampling Rate:Up to 2 MS/s per channel
Resolution:16-bit
Input Range:+/-10V, +/-5V, +/-2.5V, +/-1.25V
Input Types:Single-Ended, Differential
Data Transfer:DMA, interrupts
Software Support:LabVIEW, Measurement & Automation Explorer (MAX)
The National Instruments PCI-5105 is an essential component for any advanced data acquisition system. With its 18-channel analog input design, it offers unparalleled flexibility for capturing data from various sensors and transducers.
This module is equipped with a high-resolution 16-bit analog-to-digital converter, ensuring precise and reliable data collection. The sample rate of up to 2 MS/s per channel enables fast and accurate measurements.
Each channel can independently select input ranges, making it adaptable to a wide range of measurement scenarios. The BNC connector type ensures easy integration with standard test equipment.
Designed with ease-of-use in mind, this module requires no hardware configuration. All settings are managed through software, streamlining setup and maintenance processes.
For robust operation, the PCI-5105 supports Windows XP/7/8/10 operating systems, and is powered by a 3.3V to 5V DC power supply, making it compatible with a variety of industrial environments.
