SCHNEIDER STBDAI7220 Automation Module for Industrial Control Systems
The Schneider STBDAI7220 is a high-performance analog input module designed for industrial automation systems. It offers unparalleled precision and reliability in various industrial applications including manufacturing, process control, and data acquisition.
Brand:Schneider
Model:STBDAI7220
Module Type:Digital Input Module
Input Channels:16
Voltage Range:0-30V DC
Operating Temperature:-25°C to +70°C
Power Supply:12-24V DC
Communication Protocol:Modbus RTU
Protection Class:IP20
Weight:0.5kg
Dimensions:120mm x 100mm x 60mm
The Schneider STBDAI7220 is engineered to provide precise and reliable analog input data acquisition for a wide range of industrial processes. With its 16-channel design, it efficiently captures voltage and current signals within specified ranges, ensuring accurate measurements.
This module is compatible with Schneider’s Modicon PLC systems, making it an ideal choice for integration into existing automation frameworks. The robust communication interface supports RS485 and Modbus RTU protocols, facilitating seamless data exchange with other devices and systems.
Designed for durability, the STBDAI7220 operates over a broad temperature range from -25°C to +70°C, ensuring reliable performance in harsh environments. Its compact size and modular design make it easy to install and maintain, reducing downtime and enhancing operational efficiency.
With a sampling rate of up to 100Hz, this module can capture real-time data with minimal latency, enabling timely response to process changes. The high-resolution 16-bit converter ensures precise measurement, minimizing errors and improving overall system accuracy.
Whether you’re working in manufacturing, energy, or any other industry requiring advanced data acquisition, the Schneider STBDAI7220 offers a reliable solution. Its compatibility with Schneider’s extensive PLC ecosystem ensures seamless integration and optimal performance.
