Woodward 8200-1302 Marine/ATEX Compliance LVDC Integrated Graphical Front Panel HMI
The Woodward 8200-1302 is an advanced integrated graphical front panel Human-Machine Interface (HMI) designed specifically for marine and ATEX compliance applications. It comes with LVDC (18-32 Vdc) and is equipped with emergency trip keys, soft key commands, and LED status indicators.
Model Number:8200-1302
Brand:Woodward
Compliance:Marine/ATEX
Voltage:LVDC (18-32 Vdc)
Shutdown Features:Shutdown Raise Speed Setpoint, Reset, Lower Speed Setpoint
Control Outputs:Two 4-20 mA control outputs
Relay Contact Outputs:Eight Form-C relay contact outputs
Emergency Trip Key:Yes
Navigation Keys:Cross keys, Soft key commands, Home keys
Status Indicators:Four LEDs for control and hardware status
Operating Temperature Range:Rated for operating ambient temperatures up to 75°C
The Woodward 8200-1302 represents the pinnacle of industrial control technology. Designed specifically for marine and ATEX environments, this graphical HMI panel integrates seamlessly into complex turbine governor systems. Its rugged construction ensures reliable operation even under harsh conditions. The panel features a dedicated emergency trip key for immediate safety intervention, alongside a suite of soft keys and LED indicators that provide clear status feedback. Two 4-20 mA control outputs and eight Form-C relay contacts enable versatile integration with peripheral equipment. Furthermore, the panel’s compact design facilitates easy installation without compromising functionality. Invest in the future of industrial automation with the Woodward 8200-1302 – where precision meets dependability.
