GE IS200TRLYH1BGF Terminal Relay Card
The GE IS200TRLYH1BGF is a robust Relay Terminal Board designed for industrial control systems. It serves as an essential component in the Mark VI series by General Electric, offering reliable and efficient performance in managing electrical connections.
Brand:General Electric
Model:IS200TRLYH1BGF
Series:Mark VI
Type:Relay Terminal Board
Dimensions:33 cm x 17.8 cm x 5.5 cm
Weight:1.42 kg
Terminal Blocks:2 Long Black Terminal Blocks
Terminals per Block:24
Total Terminals:48
Relays:Vertical Line of Relays
Transistors:6 on Each Side of Relays
The GE IS200TRLYH1BGF Relay Terminal Board is an essential component for industrial automation systems, designed to provide secure connections for relays and transistors. Its robust design ensures longevity and reliability in harsh environments.
The board features two long black terminal blocks, each equipped with 24 numbered terminals, totaling 48 terminals for comprehensive connectivity. This setup allows for efficient and organized wiring, reducing the risk of errors during installation.
In the center of the board, you will find a series of relays or contactors arranged vertically, covered with transparent plastic for easy visibility. These relays are critical for controlling the flow of electrical current in various circuits.
On either side of the relays, six black transistors are positioned, further enhancing the board’s functionality. These components work together to ensure smooth and reliable operation of the connected systems.
The dimensions of the GE IS200TRLYH1BGF board are 33 cm x 17.8 cm x 5.5 cm, making it a compact yet powerful solution for industrial control needs. Weighing 1.42 kg, this board is sturdy enough to withstand the rigors of industrial settings.
